18V Brushless 10Ga Angled First Fix Framing Nailer 30˚-34˚

B18FN10

Product variations: x2
  • High power Brushless First fix framing nailer that requires no gas cartridges, no pneumatic hoses, no cables
  • Drives 10 gauge framing nails from 50mm to 90mm into soft and hard woods via compressed air spring paired with high power Brushless motor
  • Instant driving of framing nails with zero ramp up time and 2 firing modes for single fire, and bump mode for firing up to 3 nails per second
  • Accepts 30-34 degree paper collated nail magazines with capacity of 67 on standard magazine
  • Compressed air canister can be self service refilled using a standard high pressure inflator . Expect up to 20000 nails fired between refills.
  • Using a 6.0Ah battery expect to fire up to 1000 nails
  • Tool free magazine loading and tool free nail drive depth adjustment dial to set nails flush or sub flush into material
  • Dry fire lock out system restricts nail firing when magazine is empty to prevent damage to firing mechanism
  • Features HD-SYNC™ Technology which provides up to 20% more power, when combined with our High Demand Pro Lithium-ion PRO18V batteries
  • As part of the PRO18V system of professional powertools, this tool is compatible with any PRO18V battery
View More View Less

Customer Review Videos

Compare product variations

  • Product Specifications

  • Article Number
  • Battery pack capacity (Ah)
  • Battery supplied
  • Battery type
  • EAN Code
  • Magazine angle
  • Magazine capacity
  • Nail capacity (mm)
  • Nail type (mm)
  • No. of batteries supplied
  • Sound power level (Lwa)(dB(A))
  • Sound power level uncertainty (dB(A))
  • Sound pressure level (Lpa)(dB(A))
  • Sound pressure level uncertainty (dB(A))
  • Supplied in
  • Vibration level (m/s²)
  • Vibration uncertainty (m/s²)
  • Weight with battery pack (EPTA) (kg)
  • Product Data Specifications
  • Manuals & Spare Parts
    • B18FN10-602C

    • 4935498601
    • 6.0Ah
    • 2 x 6.0Ah
    • Li-ion
    • 4058546524708
    • 30-34˚
    • 67
    • 50-90mm
    • -
    • 2
    • 106,5 dB(A)
    • 3 dB(A)
    • 95.5 dB(A)
    • 3 dB(A)
    • Kitbox
    • 12,2 m/s2
    • 1.5 m/s2
    • 5.0kg (L1860SHD)
    • Download
    • View
    • B18FN10-0

    • 4935498184
    • -
    • -
    • -
    • 4058546520533
    • 30-34˚
    • 67
    • 50-90mm
    • 10 gauge
    • 0
    • 106,5 dB(A)
    • 3 dB(A)
    • 95.5 dB(A)
    • 3 dB(A)
    • Kitbox
    • 12,2 m/s2
    • 1.5 m/s2
    • 4.9 (L1840S)
    • Download
    • View
